Fiberglass Yarn

Characteristics

● Using glass yarn ball as raw material.
● It has the properties of insulation, fire prevention and softness.
● Essential raw materials for thermal insulation products.
● The twist and diameter of the wire depends on the customer's requirements.



Customization

If you have special requirements, YN supports customization of chopped strand length, monofilament diameter, tex value and other parameters.

●FREE SAMPLE

Description

"What is Fiberglass Yarn ?”
  Fiberglass yarn is electrical insulation materials ,electronic industrial fabrics,tubes and other industrial fabric raw materials. It”s widely used for circuit board,weaving all kinds of fabrics in the scope of reinforcement ,insulation,corrosion resistance,heat resistance and so on.


Specification

Fiberglass Yarn


PERFORMANCE TYPE GLASS FILAMENT DIAMETER MTYPE IN U.S.A. TWIST DEGREE
Fiberglass Yarn EC9-33×1×2 E 9μm ECG 150 1/2 S65
EC9-33×1×3 E 9μm ECG 150 1/3 S65
EC9-33×2×3 E 9μm ECG 150 2/3 S110
EC9-68×1×0 E 9μm ECG 75 1/0 Z28-35
EC9-68×1×2 E 9μm ECG 75 1/2 S28-110
EC9-136×1×0 E 9μm ECG 37 1/0 Z28-35
EC9-136×1×2 E 9μm ECG 37 1/0 S28-110
EC5.5-12×1×0 E 5.5μm ECD 450 1/0 S40
EC5.5-12×1×2 E 5.5μm ECD 450 1/2 S40
CC9-33×1×2 C 9μm CCG 150 1/2 S28-100
CC9-33×2×2 C 9μm CCG 150 2/2 S28-100
Technical Parameters

2023-03-13 187

Test Report of TEX134 C-Glass

2023-03-13 371

Test Report of TEX33 1 2

2023-03-13 653

Test Report of TEX68

2023-03-13 271

Test Report ofECR 11-136x1S28-365

2023-03-13 338

Test Report of TEX68x1x2

2023-03-13 666

Test Report of C Glass Tex100

Still can't find what you're looking for?
Please contact our consultants for more available products.

Application

1.Woven Fiberglass mesh (general yarn for warp, roving for weft)

2. Weaving various electronic cloth

3. Braided cable wire Cladding

4.Braided casing

5.Braided fuse

6.Insulation materials for making electrical windings ,etc.



Clients we have worked with


PRODUCT INQUIRY
Company info

Hebei Yuniu Fiberglass Manufaturing Co.,Ltd as a professional fiberglass enterprise, established in 2002, mainly manufactures and distributes E-glass fiber products, such as Direct Roving, Chopped strands, Chopped Strand Mat, Fiberglass mesh, Plain cloth Woven Roving, Multiaxial Fabric, Needle mat and so on.
Three production line, one is in Xintai, it is Furnace for fiberglass roving and fiberglass chopped strand mat .
The other is in Suzhou, it is the production line of fiberglass chopped strands.
The other our fiberglass mesh, the biggest production line in the north part of China.

Packaging & Shipment

Chopped Strands are packaged in kraft bags or woven bags, about 25kg per bag, 4 bags per layer, 8 layers per pallet and 32 bags per pallet, Each 32 bags of products are packed by multilayer shrink film and packing band. Also the product can be packed as the customers' reasonable requirements.
This product should be stocked in dry and cool places. The best condition is within temperature between 15-35℃, with a relative humidity between 30% and 70%. Please keep the product in its original packing before use to avoid moisture.

We are able to provide

A variety of shipping methods ensure that your goods arrive safely and quickly.





Q1:Are you a factory? Where are you located?
A: we are a manufacturer.
Q2:What's the MOQ?
A: Usually 1 Ton
Q3:Package & Shipping.
A: Normal package:carton(Incuded in the unite price)
Special Packge: need to charge according the actual situation.
Normal shipping :your nominated Freight forwarding.
Q4:When can I offer?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price pls call us or tell us in your email , so that we can reply you priority.
Q5:How do you charge the sample fees?
A: If you need a samples from our stock, we can provide to you for free, but you need to pay the freight charge.If you need a special size, We will charge the sample making fee which is refundable when you place an order.
Q6:What's your delivery time for production?
A:If we have stock , can delivery in 7 days ; if without the stock, need 7~15 days !
